YBA Genesis PH1

The PH1 caters for MM, low output MC and high output MC cartridges. Never connect MM and MC cartridges at the same time as there will be a possibility with the high amplification factor that some noise could occur at the output stage. The selector control on the front panel of the PH1 has only two options(MM or MC) even though it accepts high output MC. The circuitry has been designed so that it will automatically sense which type of moving coil cartridge is being used and settings will adjust accordingly provided the correct selection is made from the toggle switch on the rear panel.

Product type	Phono Preamplifier
Cartridge impedance	3Ω to 100Ω
Output impedance	47kΩ
Bandwidth	10 HZ to150 KHZ
Gain	26 dB
Shielding full mu-metal	Double
Moving Magnet (MM)	Input impedance 47 kOhm 45dB Gain
Moving Coil (MC)	Input impedance 47 kOhm 50dB Gain
SNR	90dB (A weighted @ 40dB input gain)
THD	<0.005%
RIAA accuracy	Within 0.3dB/20Hz – 20kHz
Inputs	2 RCA Analog Signal Inputs
Outputs	1 RCA 1 Balanced
Display	OLED
Power Supply	10 pcs NCR18650 with 24V DC power adaptor
Color / Finish	Black aluminium with black acrylic panel
Dimensions (w x d x h)	215 x 335 x 115 mm
Weight	4 kg
